BF15

ENQUIRE ABOUT THIS PRODUCT

RELIABILITY IN A COMPACT DESIGN

With a high output 350cc displacement and long-stroke design, the BF15 and BF20 are top performers, providing optimum torque at any speed. Programmed Ignition (PGM-IG) also accurately controls ignition timing during start-up and across the entire rev range for optimum overall operation.

A 12amp (electric start) alternator also ensures excellent charging power to keep batteries in top condition. Thanks to their incredible lightweight, the engines are also very easy to transport.

A foldaway handle positioned at the exact balance point of each engine makes it easy to carry the outboard in a level position.

SUPERIOR HANDLING POWER

The BF20 is equipped with Power Tilt and Gas Assist Tilt variations – perfect for effortless engine tilt operations and shallow-water running.

Cruising is improved and more comfortable with Honda’s unique pendulum-motion mounting system.
This system, featured in both the BF15 and BF20, is specially designed to reduce vibration and maximise user comfort.
A convenient Forward Mount Shift Lever allows fingertip shifting, while a Twist Grip Throttle and Tensioner ensures superior throttle friction, minimising driver fatigue.

DIMENSIONS

Recommended Transom Height

15", 20" & 25"

Dry Weight

46.5 kg

DRIVE

Gear Ratio

2.1:1

Gear Shift

F-N-R

Propellor

4 blade aluminium 9 1/4 x 10

POWER THRUST OPTION
(FOUR BLADE PROPELLER)

A Power Thrust propeller is also available for the BF15/BF20. This propeller has been matched to ensure the BF15/BF20 can be installed on and be more suited for use on heavier, slower moving
displacement type craft.

• High output 350cc displacement engine. Provides superior torque throughout the entire rev range.
• Auto Start Enrichment (on electric start models) automatically adjusts the air/fuel mixture for quick, easy starting and warm-up just like fuel injection.
• 12amp (electric start) alternator ensures battery charge is maintained while operating electronics and
  other accessories.
• Convenient foldaway handle positioned at the exact balance point of each engine makes it easy to carry the outboard in a level position.
• 4-Front Corrosion Protection. A patented, ‘double-sealed’ multi-layered paint process. Sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.

MAINTENANCE INFO

MAINTENANCE SCHEDULE

COMPONENT ID

All services carried out using Genuine Honda Parts and Oils

** Service times are based on the Maintenance Schedule in your Owner's Manual. No allowances are made for work that is to be carried out in excess of this schedule or at owner's request. Pricing does not include Parts and Consumables.**

Your Service agent can be identified via the display of this signage on there building and in addition to this should also be displaying the Honda Genuine Parts and Accessories signage.

20 Hour Service

Hours to complete

1.5

100 Hour Service

Hours to complete

2

200 Hour Service

Hours to complete

2.5
