THE RIGHT AMOUNT OF MUSCLE.

Boaters can take advantage of significantly higher engine displacement for more low and mid-range power. Even at low revs, the BF2.3 and BF5 have solid and reliable torque to move heavier hulls than other engines in their class.

EASY & COST EFFECTIVE TO OPERATE

For increased control and reduced steering effort, the BF2.3 and BF5 each have a Twist Grip Throttle which ensures superior throttle friction and enhances response and manoeuvrability. Just like the rest of Honda’s outboard range, these engines are also extremely fuel efficient.

PORTABLE POWER

Although these compact engines pack enough punch to push a boat out to sea, they’re light enough to be carried back to the car! Thanks to the ergonomic carry handle fitted to each engine, the BF2.3 and BF5 can be taken anywhere.

Despite their size, these engines boast all the benefits of Honda’s advanced four-stroke technology, which is second to none.

The BF5 features a 3amp battery charging outlet as standard equipment, as well as a safety lock-out system that allows the engines to be started only in neutral gear.

ENGINE

Type
4-stroke OHV
Displacement
57cc
Bore & Stroke
45 x 36 mm
Full Throttle RPM Range
5,000-6,000 RPM
HP Rating @ Propshaft
2.3HP
Valves per Cylinder
Two
Fuel Delivery
Carburettor
Ignition System
Solid state
Starting System
Recoil
Cooling System
Air
Alternator

DIMENSIONS

Recommended Transom Height
15" / 20"
Dry Weight
12.2 kg

DRIVE

Gear Ratio
2.42:1
Gear Shift
Centrifugal Clutch F/N 360° pivot
Propellor
3-blade plastic

BF2.3 ROTATES 360

Get in and out of tight spots with ease, or go in any direction on the compass, with this extremely maneuverable engine.

This model comes standard with a centrifugal clutch. The engine is able to maintain a smooth idle and then upon advancing the throttle it automatically engages the propeller above idle speed. It’s like having a neutral position.

AVAILABLE AS

  • Short (15") or long (20") shaft
  • Centrifugal Clutch with forward and neutral gears or gearless
  • World-renowned Honda four-stroke quality combines proven reliability and superior fuel efficiency, with no oil mixing.
  • Lightest 2.3hp four-stroke available! Even lighter than most two-stroke outboards.
  • 1L integral fuel tank facilitates easy removal and portability as one unit. (BF2.3).
  • Lightweight/compact design. Easy to transport and perfect for small tenders.
  • Twist Grip Throttle ensures precise throttle control, while the throttle tensioner minimises driver fatigue.
  • BF5 incorporates a safety lock-out system that permits the engines to be started only in neutral gear.
  • BF5 features a 3amp battery charging outlet as standard equipment.
  • 4-Front Corrosion Protection. A patented, ‘double-sealed’ multi-layered paint process. Sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.

MAINTENANCE INFO

MAINTENANCE SCHEDULE

COMPONENT ID

Service Information

All services carried out using Genuine Honda Parts and Oils

** Service times are based on the Maintenance Schedule in your Owner's Manual. No allowances are made for work that is to be carried out in excess of this schedule or at owner's request. Pricing does not include Parts and Consumables.**

Your Service agent can be identified via the display of this signage on their building and in addition to this they should also be displaying the Honda Genuine Parts and Accessories signage.

 Honda Outboard Engines NZ

20 Hour Service

Hours to complete
1

100 Hour Service

Hours to complete
1.25

200 Hour Service

Hours to complete
1.75
